V-arrangement rotor knives
The staggered rotor layout distributes cutting loads evenly, reduces feeding resistance and supports stable high-torque shredding.
Discuss this configuration →Single-shaft
Single-shaft Shredders
Controlled single-shaft size reduction for plastics, wood, paper, cable and production waste.
WLD Series
Best suited forPlastics / film / wood
Total installed power20.75–58.75 kW total
Listed model throughput0.2–0.9 t/h
Sales engineerDiscuss your application ↗Response within one business day01 · Product introduction
Built around the material and the required result.
Application-specific configurationServiceable cutting systemControlled output sizingContinuous-duty construction
Engineered around the material
Precision single-shaft shredding engineered around material, duty cycle and required output size. Tell us the feedstock, hourly capacity and target output. WALI engineers will configure the cutting system, drivetrain and downstream process for the operating conditions.
02 · Equipment features
Engineering details that affect daily operation.
Replaceable screen system
Interchangeable screens make it practical to control the required output size for different downstream processes.
Discuss this configuration →
Hydraulic horizontal pusher
The controlled pusher keeps bulky and irregular material in consistent contact with the rotor for reliable feeding.
Discuss this configuration →Automatic overload protection
The control system detects excessive load and automatically reverses the rotor to protect the drivetrain and restore operation.
Discuss this configuration →
PLC monitoring and control
Operating status, alarms and key settings are managed through the PLC interface for straightforward daily control.
Discuss this configuration →
Maintenance-oriented construction
Accessible wear parts, adjustable knives and service-friendly access help reduce routine maintenance time and operating cost.
Discuss this configuration →03 · Application range
Match the machine to the duty.
- Plastics: injection-molded parts, extrusion scrap, pipes, films and rigid plastic.
- Wood: pallets, crates, timber offcuts and production waste.
- Paper: documents, cardboard, cores and packaging waste.
- Cables: copper cable, aluminum cable and mixed power cable.
- Aluminium: profiles, cans and light aluminum scrap.
- Textiles: garments, fabric offcuts and carpet waste.
- Foam: PU foam, insulation foam and upholstery foam.
- Composite materials: glass-fibre products, automotive trim and rubber composite parts.
- Secure destruction: rejected, counterfeit and expired products.
Rotor geometry, knife configuration, screen opening and feeding strategy are selected around the material, contamination level, required throughput and target output size. This allows the WLD series to produce a stable, application-specific result for downstream separation, granulation or recycling.
Direct engineering contact
Need a quotation or configuration advice?
Send your material, hourly capacity and target output. A WALI engineer will help define a practical starting point.
Talk to an engineer →
APPLICATION ENGINEERING · WALIMachine in operation
See the machine working with real material.
Watch the feeding, stable processing and resulting output under real operating conditions.
04 · Compare models
WLD Series model range.
Use this table for preliminary comparison. Final throughput depends on the material, feeding consistency and screen configuration. Power summaries add the listed installed motors; capacity ranges span the listed model values and remain material-dependent.
| Specifications | WLD-600 | WLD-800 | WLD-1000 |
|---|---|---|---|
| Drive power | 18.5+2.25 kW | 45+3.75 kW | 55+3.75 kW |
| Cutting chamber | 600*500 mm | 800*780 mm | 1000*780 mm |
| Typical throughput | 200-300 kg/h | 500-800 kg/h | 700-900 kg/h |
| Typical output | 30-100 mm | 30-100 mm | 30-100 mm |
Technical documents
View product information.
Open a brochure online before deciding whether to download it. Contact our team for a project-specific configuration.
PDFProduct brochure
Successful applications
View all projects ↗Projects using WALI equipment.
CompletedJiangsu China
Bulky Waste Recycling Solution- Jiangsu-Suqian
One-Stop Crushing & Separation Solution
View project ↗
CompletedNanjing China
Bulky Waste Recycling Solution-Nanjing-Qilin
One-Stop Crushing & Separation Solution
View project ↗
CompletedNanjing China
Bulky Waste Recycling Solution-Nanjing-Gaochun
One-Stop Crushing & Separation Solution
View project ↗Real factory delivery
Built, checked and prepared for delivery.
Selected packing and shipment records associated with this equipment family.
View factory delivery records ↗Indirect export via China
WLD
This single-shaft shredder was supplied to a customer in Nantong, China, for onward export to Russia.
Frequently asked questions
Before you choose a machine.
Clear answers about selection, manufacturing, delivery and support.
Are you a factory or a trading company?
WALI is an industrial shredder and recycling equipment manufacturer with its own production and assembly capabilities.
Where is your company?
WALI's manufacturing base is located in Anhui Province, China, with convenient access for international customer visits.
How do you ensure that the machine I order is suitable for my material?
Send us material photos or samples, hourly capacity, target output size and operating conditions. Our engineers will review the application and recommend a suitable machine and cutting configuration.
Do you support OEM and ODM?
Yes. Machine configuration, color, branding and line layout can be discussed according to the project requirements.
What is the minimum order quantity?
The usual minimum for equipment is one machine or one set. Spare and wear-part quantities depend on the specific item; please confirm them with our sales team.
How do you ensure machine quality?
Critical materials, machining, assembly and inspection are controlled through the production process, and the machine is tested before delivery.
How long is the delivery time?
Delivery depends on the selected model, customization and production schedule. A confirmed lead time is provided after the technical scope is agreed.
What are your payment terms?
Payment terms are confirmed in the official quotation and contract for each project.
How are the machines packed?
Equipment is protected for export shipment according to its dimensions, weight and selected transport method.
What is the warranty period?
The applicable warranty period and coverage are stated in the project quotation and contract. Please confirm these terms before ordering.
How do you provide after-sales service?
Support can include remote technical guidance, documentation, spare parts and on-site commissioning where agreed in the project scope.
Do you provide training?
Operating and maintenance training can be provided remotely or on site according to the agreed project scope.
Will you provide technical documents?
Operating manuals and the technical documents included in the agreed supply scope are provided with the project.
What shipping methods do you support?
Sea and land freight are commonly used for machinery, while suitable parts may also be shipped by air or express. The final method depends on destination and cargo size.
Can this equipment be customized?
Yes. The cutting system, drive, controls, dimensions and line integration can be configured according to the project.
